Horizontal Blast Cleaning Machines we manufacture and supply, include a wide range of machines specifically designed for horizontal section, profile, pipe and plate cleaning. The machines are fitted with four, six or eight wheel units, depending on the size and intended application.



In Stock

Pangborn UK offers a range of blast cleaning machines for horizontal section, profile, pipe and plate cleaning. The machines are fitted with 4, 6 or 8 wheel units depending on size and application. They are suitable for medium to large structural steel or fabrication companies.

NOTE:

Designs differ in the number and placement of blast wheels and air nozzles, and incorporate a variety of material handling systems.

Specifications

Blast Wheel Speed
Variable from 2200 to 3800 RPM when fitted with optional electronic inverter control.

Blast Wheel Type
Pangborn RIM-LOC 8 Vane type reversible rotoblast wheels, achieve faster Cleaning and feature the easiest and quickest maintenance vane change in the industry.

Machine Operating Speed
When fitted with 11.0 kW wheel motors the average throughput speed is 1.5 m per minute when cleaning to SA2.5. When fitted with 18.5 kW wheel motors the average throughput speed is 2.0 m (6D3000) / 1.5 m (8D3500) per minute when cleaning to SA2.5.

Abrasive Control System
Individual quadrant valves on each wheel activated by sensor or manual push button.

Blast Cabinet Protection
Cross rolled manganese steel.

Blast Cabinet Floor
High chrome alloy steel perforated floor plates.

Abrasive Recovery System
Heavy duty screw conveyors, belt and bucket elevator and rotary sieve type airwash unit.

PDF DATA SHEET
